Product Overview: LMKDB1120Z100NPPT The LMKDB1120Z100NPPT is a high-performance, 20-output LP-HCSL clock buffer designed by Texas Instruments to meet the stringent jitter requirements of next-generation data centers. As a DB2000QL compliant device, it is specifically engineered for PCIe Gen 1 to Gen 7 applications, supporting frequencies up to 400 MHz. This specific variant is optimized for 100-Ω differential output impedance, ensuring seamless signal integrity in standardized enterprise server environments. Featuring an industry-leading additive jitter of approximately 2.1 fs (PCIe Gen 7),...
Please hurry! Only 0 left in stock
10 customers are viewing this product
Couldn't load pickup availability
Description
xProduct Overview: LMKDB1120Z100NPPT
The LMKDB1120Z100NPPT is a high-performance, 20-output LP-HCSL clock buffer designed by Texas Instruments to meet the stringent jitter requirements of next-generation data centers. As a DB2000QL compliant device, it is specifically engineered for PCIe Gen 1 to Gen 7 applications, supporting frequencies up to 400 MHz. This specific variant is optimized for 100-Ω differential output impedance, ensuring seamless signal integrity in standardized enterprise server environments. Featuring an industry-leading additive jitter of approximately 2.1 fs (PCIe Gen 7), it minimizes data errors in high-speed communication backplanes. AICCHIP provides reliable B2B wholesale access to these original TI components, dispatched directly from our China logistics hubs with full support for global distribution to Europe, the US, and Russia.
Key Technical Advantages
- PCIe Gen 7 Readiness: Delivers ultra-low additive jitter, ensuring your system remains compliant with the latest high-speed interconnect standards.
- Standardized 100-Ω Outputs: Pre-configured for 100-Ω differential impedance, reducing the need for external termination components and simplifying PCB layout.
- Scalable Distribution: 20 independent LP-HCSL outputs allow for massive clock tree expansion with minimal skew between channels.
- Flexible Power Architecture: Operates on dual 1.8V or 3.3V rails, offering the power efficiency required for modern green-energy server racks.
Detailed Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | Texas Instruments (TI) |
| Part Number | LMKDB1120Z100NPPT |
| Output Impedance | 100-Ω (Differential) |
| Number of Outputs | 20 (LP-HCSL) |
| PCIe Support | Gen 1, 2, 3, 4, 5, 6, 7 |
| Core Frequency | Up to 400 MHz |
| Package Type | 80-TLGA (6.0 mm x 6.0 mm) |
| Compliance | Intel DB2000QL Standard |
